Looking for high brightness and wide temperature range for outdoor applications?
Check our new displays with 10.4” and 12.1” XGA. They offer both.
10.4” XGA with 1300 cd/m² – P1040XGF1MA00
The new displays with 10.4” and 12.1” XGA (1024 x 768) from the recently introduced P-series are dedicated for outdoor applications. They offer a luminance between 800 cd/m² and 1300 cd/m². Due to SFT-technology (normally black) each display allows wide viewing angle of 88° from any direction. All displays are with LVDS interface. High luminance displays are normally without integrated backlight driver, allowing to design a customized driver solution for each specific application. The typical backlight lifetime is 70kh respectively 100kh. The operating temperature range is -30°C … +80°C.
- XGA (1024 x 768) resolution
- SFT-technology (normally black) for wide viewing angle (88°/88°/88°/88°)
- LVDS interface
- Without integrated backlight driver
- Operating temperature range -30°C … +80°C
Size in inch
Luminance in cd/m²
Samples can be ordered
MP in Q2/2022 (10.4”) respectively Q3/2022 (12.1”)
